011
Gas suitability
LR measures stable single-component or mixed dry gas, excluding acetylene and hydrogen. The catalog lists gases such as air, oxygen, nitrogen, argon and helium, among others.
Product family
Thermal Mass Flow Meters
LR thermal mass flow meters for gas, flange DN25 to DN150, measuring gas mass flow directly without external temperature or pressure correction.
• Direct gas mass flow, no temperature or pressure correction • Accuracy ±(1.5+0.5FS)% • 4-20 mA, pulse, RS485 and HART
Product
LR Flanged Thermal Mass Flow Meter for Gas
LR flanged thermal mass flow meter for dry gas, flange DN25 to DN150, direct mass flow without pressure or temperature correction.
Selection guidance
How to specify a thermal mass flow meter
Three inputs decide the LR configuration.
022
Connection and pipe size
The flanged version covers DN25 to DN150. The same family also offers thread (DN25 to DN50) and insertion (DN125 to DN2000) versions.
033
Range and output
Accuracy is ±(1.5 + 0.5 FS)%. Normal medium velocity is 0.56 to 56 Nm/s, extended to 100 Nm/s by arrangement. Outputs include 4-20 mA, pulse, RS485 and HART.
Get a Quote
Need help choosing a thermal mass flow meter?
Send the gas type and composition, pipe size, flow range, pressure and temperature and we will confirm suitability and the output configuration.
Include
Gas type and composition, pipe size, flow range, pressure, temperature and output.
