LZT-4T Acrylic Rotameter
LZT-4T panel-mount acrylic rotameter with quick-connect fitting for very low liquid and gas flows, part of the LZT acrylic variable-area series.
Specifications
- Series
- LZT acrylic variable-area flow meter
- Model
- LZT-4T (panel-mount, quick-connect)
- Tube / Body Material
- Acrylic (organic glass) tube
- Medium
- Liquid or gas, depending on model selection
- Liquid Flow Range
- 6-60, 8-80, 10-100, 40-400 ml/min (selectable)
- Gas Flow Range
- 0.1-1, 0.25-2.5, 0.6-6, 1-4, 1-10, 1-12 L/min (selectable)
- Connection
- Quick-connect (fast connector)
- Accuracy
- ±4% of full scale
- Adjusting Valve
- T = with valve; O = without valve
- Wetted Material Options
- Brass / chrome-plated brass / stainless steel; O-ring VMQ, FKM or NBR
Where the LZT-4T Fits
The LZT-4T is the quick-connect panel meter in the LZT acrylic variable-area family. It is used where very low liquid or gas flows must be read directly on a compact panel indicator.
It shares the LZT acrylic metering principle with the LZT-6T and LZT-8T, but uses a quick-connect fitting instead of the internal G1/4 in panel interface.
Construction and Specifications
The metering tube is acrylic (organic glass). Accuracy is ±4% of full scale. Liquid ranges are shown in ml/min and gas ranges in L/min, so a single body covers several low-flow duties by scale selection.
The adjusting valve is optional (T = with valve, O = without valve). Interface material may be brass, chrome-plated brass or stainless steel; O-ring may be VMQ, FKM or NBR.
Ordering Guidance
Provide the medium (liquid or gas), the required flow range and the connection to confirm the LZT-4T scale and valve option.
